This is an example of how to a client application retrieves a token from a Identity Server and use it in an WebApi to consumes an endpoint.
How this project was created
This example was built based on Duende documentation
Identity Server
Identity provider for our sample.
Install Duende templates
dotnet new --install Duende.IdentityServer.Templates
Create an empty solution
dotnet new sln -n IdentityServerDemo
Create Identity server project
dotnet new isempty -n IdentityServer
Add IdendityServer projet to the blank solution
dotnet sln add .IdentityServerIdentityServer.csproj
Add scope to config.cs
public static IEnumerable<ApiScope> ApiScopes =>
new ApiScope[]
{ new ApiScope(name: "campelo-api", displayName: "CampeloAPI") };
Add client to config.cs
public static IEnumerable<Client> Clients =>
new Client[]
{ new Client
{
ClientId = "client",
// no interactive user, use the clientid/secret for authentication
AllowedGrantTypes = GrantTypes.ClientCredentials,
// secret for authentication
ClientSecrets =
{
new Secret("secret".Sha256())
},
// scopes that client has access to
AllowedScopes = { "campelo-api" }
} };
Openid-configuration
Now you can access openid-configuration from the identity server. Run the solution and go to https://localhost:5001/.well-known/openid-configuration. So you can retrieve something like this.
{
"issuer":"https://localhost:5001",
"jwks_uri":"https://localhost:5001/.well-known/openid-configuration/jwks",
"authorization_endpoint":"https://localhost:5001/connect/authorize",
"token_endpoint":"https://localhost:5001/connect/token",
"userinfo_endpoint":"https://localhost:5001/connect/userinfo",
"end_session_endpoint":"https://localhost:5001/connect/endsession",
"check_session_iframe":"https://localhost:5001/connect/checksession",
"revocation_endpoint":"https://localhost:5001/connect/revocation",
"introspection_endpoint":"https://localhost:5001/connect/introspect",
"device_authorization_endpoint":"https://localhost:5001/connect/deviceauthorization",
"backchannel_authentication_endpoint":"https://localhost:5001/connect/ciba",
"frontchannel_logout_supported":true,
"frontchannel_logout_session_supported":true,
"backchannel_logout_supported":true,
"backchannel_logout_session_supported":true,
"scopes_supported":[
"openid",
"campelo-api",
"offline_access"
],
"claims_supported":[
"sub"
],
"grant_types_supported":[
"authorization_code",
"client_credentials",
"refresh_token",
"implicit",
"urn:ietf:params:oauth:grant-type:device_code",
"urn:openid:params:grant-type:ciba"
],
"response_types_supported":[
"code",
"token",
"id_token",
"id_token token",
"code id_token",
"code token",
"code id_token token"
],
"response_modes_supported":[
"form_post",
"query",
"fragment"
],
"token_endpoint_auth_methods_supported":[
"client_secret_basic",
"client_secret_post"
],
"id_token_signing_alg_values_supported":[
"RS256"
],
"subject_types_supported":[
"public"
],
"code_challenge_methods_supported":[
"plain",
"S256"
],
"request_parameter_supported":true,
"request_object_signing_alg_values_supported":[
"RS256",
"RS384",
"RS512",
"PS256",
"PS384",
"PS512",
"ES256",
"ES384",
"ES512",
"HS256",
"HS384",
"HS512"
],
"authorization_response_iss_parameter_supported":true,
"backchannel_token_delivery_modes_supported":[
"poll"
],
"backchannel_user_code_parameter_supported":true
}
API project
Web API project.
Create a new web API project
dotnet new webapi -n WebApi
Adding webapi to the solution
dotnet sln add .WebApiWebApi.csproj
Adding JWT Bearer authentication
dotnet add .WebApiWebApi.csproj package Microsoft.AspNetCore.Authentication.JwtBearer
Set JWT Bearer as the default authentication scheme
Update the Program.cs or Startup.cs file.
builder.Services.AddAuthentication("Bearer")
.AddJwtBearer("Bearer", options =>
{
options.Authority = "https://localhost:5001";
options.TokenValidationParameters = new TokenValidationParameters
{
ValidateAudience = false
};
});
/// UseAuthentication right before UseAuthorization
app.UseAuthentication();
app.UseAuthorization();
Add a new controller for testing
[Route("identity")]
[Authorize]
public class IdentityController : ControllerBase
{
[HttpGet]
public IActionResult Get()
{
return new JsonResult(from c in User.Claims select new { c.Type, c.Value });
}
}
Configure the WebAPI to listen on Port 6001
Edit the launchSettings.json file in Properties folder.
"applicationUrl": "https://localhost:6001"
Run the WebAPI project
Now you have a 401 (unauthorized) error response when trying to access https://localhost:6001/identity
Client project
Create a console client project
dotnet new console -n Client
Add the client project to the solution
dotnet sln add .ClientClient.csproj
Add IdentityModel to the client project
dotnet add .ClientClient.csproj package IdentityModel
Discover endpoints from metadata
var client = new HttpClient();
var disco = await client.GetDiscoveryDocumentAsync("https://localhost:5001");
if (disco.IsError)
{
Console.WriteLine(disco.Error);
return;
}
Request token
var tokenResponse = await client.RequestClientCredentialsTokenAsync(new ClientCredentialsTokenRequest
{
Address = disco.TokenEndpoint,
ClientId = "client",
ClientSecret = "secret",
Scope = "campelo-api"
});
if (tokenResponse.IsError)
{
Console.WriteLine(tokenResponse.Error);
return;
}
Console.WriteLine(tokenResponse.AccessToken);
Call WebAPI
var apiClient = new HttpClient();
apiClient.SetBearerToken(tokenResponse.AccessToken);
var response = await apiClient.GetAsync("https://localhost:6001/identity");
if (!response.IsSuccessStatusCode)
{
Console.WriteLine(response.StatusCode);
}
else
{
var doc = JsonDocument.Parse(await response.Content.ReadAsStringAsync()).RootElement;
Console.WriteLine(JsonSerializer.Serialize(doc, new JsonSerializerOptions { WriteIndented = true }));
}
Run client
Be sure that the IdentityServer and WebAPI are running and run the Client project to see something like this
