Installing Kubernetes using Kubeadm utility

installing-kubernetes-using-kubeadm-utility

This guide covers the step-by-step process of installing Kubernetes using the kubeadm utility. kubeadm is a tool recommended for bootstrapping a Kubernetes cluster. We will use 3 nodes: a master node and 2 worker nodes. The nodes will run on AWS EC2 instances with Ubuntu 20.04 LTS (t2.medium instance type, 8GB storage). You can use any cloud provider to launch the instances.

Prerequisites

Infrastructure Requirements:

  • Instance Type: t2.medium or better.
  • Storage: 8GB minimum.
  • Operating System: Ubuntu 20.04 LTS.
  • Network: Ensure all nodes are in the same VPC with required ports opened.

Tools:

  • SSH client (e.g., ssh or PuTTY).
  • curl, vi or nano (pre-installed in Ubuntu).

Required Ports: (Ensure these are allowed in the security group)

These ports are required for the Kubernetes cluster to work. Check the Kubernetes documentation for more information.

Master Node:

  • TCP: 6443 (Kubernetes API Server)
  • TCP: 2379-2380 (Etcd)
  • TCP: 10250 (Kube Scheduler)
  • TCP: 10257 (Kube Controller Manager)
  • TCP: 10250 (Kubelet API)
  • TCP: 22 (SSH)
  • ICMP: (Ping Connection)

Master node inbound rules

Worker Nodes:

  • TCP: 10256 (Kube Proxy)
  • TCP: 30000-32767 (NodePort Services)
  • TCP: 10250 (Kubelet API)
  • TCP: 22 (SSH)
  • ICMP: (Ping Connection)

Worker node inbound rules

Step-by-Step Setup

1. Launch EC2 Instances

  • Configuration:

    • Instance Type: t2.medium
    • AMI: Ubuntu 20.04 LTS
    • Storage: 8GB
    • Key Pair: Create or use an existing one.
    • Assign Public IP: Yes.
  • Result: Master and Worker Nodes

    Master and Worker Nodes

2. Connect to Instances and Set Hostnames

Setting a hostname ensures each node has a unique identifier, simplifying management and troubleshooting.

Master Node

ssh -i "key-pair-name.pem" ubuntu@master-node-ip
hostnamectl set-hostname master

Master Node

Worker Nodes (worker-1, worker-2)

ssh -i "key-pair-name.pem" ubuntu@worker-node-ip
hostnamectl set-hostname worker-[1-2]

Worker Node 1 Worker Node 2

3. Test Node Connectivity

Verifies that the nodes can communicate with each other, which is essential for Kubernetes components to function correctly.

From Master Node

ping worker-1-ip
ping worker-2-ip

test-connectivity

4. Disable Swap memory on all nodes

Kubernetes requires swap to be disabled to ensure proper memory allocation for containers.

Temporary (until reboot)

sudo swapoff -a

Permanent

sudo sed -i.bak '/ swap / s/^/#/' /etc/fstab

disable-swap-master
disable-swap-worker-1
disable-swap-worker-2

5. Enable Overlay and Bridge Filtering Modules

These kernel modules enable container network communication and ensure traffic routing works properly within the cluster. These settings allow the Kubernetes networking model to function correctly by enabling packet forwarding and bridge filtering.

cat <<EOF | sudo tee /etc/modules-load.d/k8s.conf
overlay
br_netfilter
EOF
sudo modprobe overlay
sudo modprobe br_netfilter
# sysctl params required by setup, params persist across reboots
cat <<EOF | sudo tee /etc/sysctl.d/k8s.conf
net.bridge.bridge-nf-call-iptables  = 1
net.bridge.bridge-nf-call-ip6tables = 1
net.ipv4.ip_forward                 = 1
EOF

Load overlay and br_netfilter modules then set params for setup - master
Load overlay and br_netfilter modules then set params for setup - worker-1
Load overlay and br_netfilter modules then set params for setup - worker-2

Apply sysctl params without reboot

sudo sysctl --system

Apply sysctl params without reboot - master
Apply sysctl params without reboot - worker-1
Apply sysctl params without reboot - worker-2

Verify br_netfilter and overlay modules are loaded

lsmod | grep br_netfilter
lsmod | grep overlay
# Verify that the net.bridge.bridge-nf-call-iptables, net.bridge.bridge-nf-call-ip6tables, and net.ipv4.ip_forward system variables are set to 1 in your sysctl config by running the following command:
sysctl net.bridge.bridge-nf-call-iptables net.bridge.bridge-nf-call-ip6tables net.ipv4.ip_forward

Verify br_netfiltler and overlay are loaded then verify sysctl params - master
Verify br_netfiltler and overlay are loaded then verify sysctl params - worker-1
Verify br_netfiltler and overlay are loaded then verify sysctl params - worker-2

6. Install Container Runtime (Containerd)

Downloads and extracts containerd, which is a lightweight and efficient container runtime for Kubernetes.

curl -LO https://github.com/containerd/containerd/releases/download/v2.0.0/containerd-2.0.0-linux-amd64.tar.gz
sudo tar Cxzvf /usr/local containerd-2.0.0-linux-amd64.tar.gz

Install containerd master
Install containerd worker-1
Install containerd worker-2

Install containerd service file and generate default configurations

Donwloads and installs the containerd service file, which is responsible for managing the containerd runtime and generates a default configuration file for containerd.

curl -LO https://raw.githubusercontent.com/containerd/containerd/main/containerd.service
sudo mkdir -p /usr/local/lib/systemd/system/
sudo mv containerd.service /usr/local/lib/systemd/system/
sudo mkdir -p /etc/containerd
containerd config default | sudo tee /etc/containerd/config.toml

Install containerd service file and generate default configurations for master
Install containerd service file and generate default configurations for worker-1
Install containerd service file and generate default configurations for worker-2

Set SystemdCgroup to true in runc.options

This configuration change enables the use of systemd cgroups for managing the resources and lifecycle of containers in the containerd runtime, which can potentially improve performance and reliability.

  1. Open the /etc/containerd/ config.toml file using the vi text editor:
sudo vi /etc/containerd/config.toml
  1. Navigate to the plugins.'io.containerd.cri.v1.runtime'.containerd.runtimes.runc.options section of the configuration file.

  2. Add the following line to this section:
    plugins.'io.containerd.cri.v1.runtime'.containerd.runtimes.runc.options

SystemdCgroup = true

Add
Add
Add

Reload Systemd Daemon and Enable Containerd Service

Reloads systemd to recognize the containerd service and enables it to start automatically.

sudo systemctl daemon-reload
sudo systemctl enable --now containerd
sudo systemctl status containerd.service

Reload the systemd daemon and enable the containerd service for master
Reload the systemd daemon and enable the containerd service for worker-1
Reload the systemd daemon and enable the containerd service for worker-2

Install Runc Runtime

Downloads and installs the runc runtime, a lightweight and efficient container runtime for Kubernetes. Runc is required by Containerd to manage and run containers based on OCI specifications.

curl -LO https://github.com/opencontainers/runc/releases/download/v1.2.2/runc.amd64
sudo install -m 755 runc.amd64 /usr/local/sbin/runc

Runc installation - master
Runc installation - worker-1
Runc installation - worker-2

Install Containerd Container Networking Interface (CNI)

Downloads and installs the CNI plugins, which are essential for container networking in Kubernetes. A CNI is required for container networking, allowing containers to communicate with each other and with external networks.

curl -LO https://github.com/containernetworking/plugins/releases/download/v1.6.0/cni-plugins-linux-amd64-v1.6.0.tgz
sudo mkdir -p /opt/cni/bin
sudo tar Cxzvf /opt/cni/bin cni-plugins-linux-amd64-v1.6.0.tgz

CNI installation containerd - master
CNI installation containerd - worker-1
CNI installation containerd - worker-2

7. Install Kubeadm, Kubelet and Kubectl.

Installs Kubernetes tools like kubeadm, kubelet, and kubectl, which are essential for managing and deploying Kubernetes clusters.

sudo apt-get update
sudo apt-get install -y apt-transport-https ca-certificates curl gpg
curl -fsSL https://pkgs.k8s.io/core:/stable:/v1.31/deb/Release.key | sudo gpg --dearmor -o /etc/apt/keyrings/kubernetes-apt-keyring.gpg
echo 'deb [signed-by=/etc/apt/keyrings/kubernetes-apt-keyring.gpg] https://pkgs.k8s.io/core:/stable:/v1.31/deb/ /' | sudo tee /etc/apt/sources.list.d/kubernetes.list
sudo apt-get update
sudo apt-get install -y kubelet kubeadm kubectl
sudo apt-mark hold kubelet kubeadm kubectl

Verify Kubeadm, Kubelet and Kubectl

kubeadm version
kubelet --version
kubectl version --client

kubeadm, kubelet and kubectl installation - master
kubeadm, kubelet and kubectl installation - worker-1
kubeadm, kubelet and kubectl installation - worker-2

Configure Crictl to Work with Containerd

Configures crictl to communicate with containerd, which is the container runtime used by Kubernetes.

sudo crictl config runtime-endpoint unix:///var/run/containerd/containerd.sock

Configuring Kubernetes Kubelet with Kubeadm

Configures the Kubernetes Kubelet to work with Kubeadm, which is responsible for managing the cluster’s nodes.

sudo bash -c "cat < /var/lib/kubelet/config.yaml
# kubeadm-config.yaml
kind: ClusterConfiguration
apiVersion: kubeadm.k8s.io/v1beta4
kubernetesVersion: v1.21.0
---
kind: KubeletConfiguration
apiVersion: kubelet.config.k8s.io/v1beta1
cgroupDriver: systemd
EOF"

kubelet configuration - master
kubelet configuration - worker-1
kubelet configuration - worker-2

8. Setup Kubernetes Cluster

Bootstraps the master node, specifying the network CIDR and the API server’s address.

Master Node

sudo kubeadm init --pod-network-cidr=192.168.0.0/16 --apiserver-advertise-address= --node-name master

kubeadm init

Setup Kubectl for Regular User and List the Nodes

Configures kubectl to interact with the cluster.

mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config

kubectl get nodes

nodes

Install Calico CNI on Master Node

Deploys Calico as the network plugin for Kubernetes, enabling pod communication across the cluster.

kubectl create -f https://raw.githubusercontent.com/projectcalico/calico/v3.28.0/manifests/tigera-operator.yaml
curl -O https://raw.githubusercontent.com/projectcalico/calico/v3.28.0/manifests/custom-resources.yaml
kubectl apply -f custom-resources.yaml

Calico-cni

Get All Pods

kubectl get pods -A

All pods on master node

Generate a token for worker nodes and run the output command on worker nodes

kubeadm token create --print-join-command

Output should be similar to this:

kubeadm join 10.0.0.10:6443 --token  --discovery-token-ca-cert-hash sha256:<hash>

kubeadm join - worker-1
kubeadm join - worker-2

List all the nodes in the cluster

After successfully joining the worker nodes to the cluster, list the nodes in the cluster.

kubectl get nodes

List all the nodes in the cluster

9. Deploy an Nginx Pod and Expose it as a NodePort Service

Deploys a sample application (Nginx) and makes it accessible outside the cluster for testing.

kubectl run nginx --image=nginx --port=80
kubectl expose pod nginx --port=80 --target-port=80 --type=NodePort

Deploy an Nginx pod and expose it as a NodePort service

Nginx Page in the Browser

Nginx page in the browser

Notes

  • Troubleshooting:

    • Use kubectl describe node for node issues.
    • Use kubectl logs for pod issues.
    • Verify CNI installation using kubectl get pods -n kube-system.
  • Next Steps:

    • Monitor the cluster using tools like Prometheus.
    • Scale up the cluster with additional worker nodes.

Conclusion

Congratulations! 🎉 You’ve successfully deployed a Kubernetes cluster using kubeadm and set up a sample Nginx application to validate your setup. This guide has walked you through every step, from preparing your nodes to launching your first pod. With your Kubernetes cluster up and running, you’re now ready to explore the endless possibilities it offers, from deploying scalable applications to experimenting with advanced concepts like autoscaling, monitoring, and service meshes.
