OAuth In a Nutshell



OAuth, which stands for “Open Authorization,” is an open standard for access delegation. It’s used in internet security to authorize users and applications to access specific resources without exposing the user’s credentials (like usernames and passwords). Let’s break down the name and its working mechanism:

Understanding the OAuth Flow

OAuth facilitates a secure method for resource owners to authorize applications to access their information (like email, username) stored on resource servers (such as Google, Facebook, etc.).

A Simplistic Approach would be to directly provide your username and password to the application, allowing it to log into the resource server on your behalf. However, this is clearly not advisable due to significant security risks.

To address this, the Open Authorization (OAuth) standard was developed. It enables a more secure authorization process:

  1. Initiating Authorization:

    • The resource owner is redirected to the resource server’s authentication interface. This step ensures that the resource owner’s credentials are not exposed to the application.
  2. Consent and Permissions:

    • The resource server displays a consent screen, listing the specific resources the application requests access to: email address, birthday, username, profile image, etc.
    • The resource owner reviews these requests and can choose to grant the necessary permissions.
  3. Authentication and Redirect:

    • Upon agreeing to the consent, the resource owner logs in to the resource server. This login process is handled directly by the resource server, maintaining the confidentiality of the resource owner’s credentials.
    • Post-login, the resource owner is redirected back to the application. At this stage, an authorization token is provided – a short-lived and securely generated code intended for one-time use.
  4. Token Exchange:

    • The application then exchanges this authorization token for an access token through a secure back-channel communication with the resource server.
    • The access token, unlike the resource owner’s credentials, is limited in scope and duration.
  5. Accessing Resources:

    • Finally, the application uses the access token to make requests to the resource server. This token acts as a key, unlocking access to the resource owner’s data as per the granted permissions, without exposing sensitive login details.

In essence, OAuth provides a robust and secure mechanism for delegating access to resources, ensuring that applications can interact with resource servers on behalf of the user, while maintaining the integrity and confidentiality of the user’s credentials.

Perspective on OAuth Implementation

For Resource Servers

  • To enable client applications to access the information of resource owners stored on your server, it’s essential to implement the OAuth (Open Authorization) Standard.
  • Implementation Steps:
    • Establish an Authentication Server to manage the OAuth process.
    • Implement a mechanism to validate access tokens received from clients.
    • Define and manage a set of permissions that can be granted via OAuth, such as:
      • Access to the resource owner’s username.
      • Access to the resource owner’s email address.
      • Access to the resource owner’s profile image.
    • Create a registration portal for client applications. It serves to authenticate the identity of client applications, issue necessary credentials (id, secret to initiate an oauth flow), configure access scopes, and ensure compliance with terms and legal requirements.

For Authentication Servers

  • Facilitate the OAuth flow by:
    • Allowing client applications to redirect users to your authentication interface.
    • Clearly displaying the permissions requested by the client application to the user.
    • Authenticating the resource owner securely.
  • Post-authentication, redirect resource owners back to the client application:
    • Include an authorization token with the redirect.

For Client Applications

  • Register your application with the resource server to get started:
    • Provide your application’s name.
    • Specify the resources you intend to access on behalf of the resource owner.
  • Manage the OAuth process:
    • Redirect the resource owner to the authentication server’s login interface.
    • Upon redirection back from the authentication server, exchange the authorization token for an access token.
    • Store the access token securely, treating it as a session token, and include it in subsequent requests to the resource server.

Appendice (NextAuth handles the oauth-flow on behalf of Client Application)

Image description
