Introduction
Before starting, take a deep breath, maybe 5 minutes of meditation and prepare a drink because this tutorial imply Rust code. Not complex, but Rust code.
But first, let’s talk about Protobuf, what is it?
1. What is Protobuf?
According to the documentation:
“Protocol Buffers are language-neutral, platform-neutral extensible mechanisms for serializing structured data.”
JSON is really flexible when you want to share data through services you can decode JSON without knowing it’s structure first.
But it is unstructured, takes a lot of space and bandwith.
With Protocol Buffers you define a message and its structure that must be known by both the server and the client to encode and decode.
// user.proto
syntax = "proto3";
message User {
string firstname = 1;
string lastname = 2;
string email = 3;
}
You can then use generators to create the SDKs for your favorites languages. You can generate a Javascript one for your frontend and a Rust one for your backend.
If you are using Remote Procedure Call (RPC) like gRPC, you can leverage the features of Protobuf and the generators to automatically generate interfaces and code for both your client and server SDKs.
The only thing you have to do next, is implement the methods of your services.
// user.proto
syntax = "proto3";
message LoginRequest {
string email = 1;
string password = 2;
}
service Auth {
rpc Login (LoginRequest) returns (User);
}
2. What are you we to accomplish
- Create a PostgreSQL database using Docker and Docker compose
- Create Protobuf definitions and use Buf to generate the SDKs
- Setup a gRPC server in Rust using Tonic
- Create a JWT authentication system with Diesel and Tonic
3. Requirements
You must have a basic understanding of Rust, I will not deep dive into how to write Rust. As I am myself, a Rust beginner. But I encourage you to check the different crates documentation to have a better understanding on how everything works.
You must know how JWT works as I will not explain it in this blog post.
You must have all the required tools installed:
If you are lost somewhere, or you directly want to go straigth to the code, the repository is available here https://github.com/kerwanp/rust-proto-demo.
Get started
1. Create the PostgreSQL database
As we want to persist our users we need a database. We are going to use PostgreSQL.
For simplicity of use, we will use Docker Compose to manage it. Make sure you have Docker installed before.
In your root folder add the following docker-compose.yml
file:
# docker-compose.yaml
version: "3"
services:
db:
image: postgres
restart: always
ports:
- "5432:5432"
environment:
POSTGRES_USER: rustproto
POSTGRES_PASSWORD: rustproto
You can then run the command docker compose up -d
to start your database (-d
will start it in background mode).
2. Create the Protobuf definitions
Protobuf definitions allows 2 things:
- Define how gRPC server and client communicate together
- Generate SDKs using Protobuf generators
We will store them in a folder called proto
Creating the Auth service Protobuf definitions
We will need two methods in our service:
-
Register
: To create a new user. It returns aToken
. -
Login
: To generate a newToken
if credentials are valid.
// proto/auth.proto
syntax = "proto3";
package auth;
message LoginRequest {
string username = 1;
string password = 2;
}
message RegisterRequest {
string firstname = 1;
string lastname = 2;
string email = 3;
string password = 4;
}
message Token {
string access_token = 1;
}
service Auth {
rpc Login (LoginRequest) returns (Token);
rpc Register (RegisterRequest) returns (Token);
}
Creating the Greeting service definitions
To test that our authentication works we need a random service that will throw an unauthenticated status if the access token is invalid.
// proto/greeting.proto
syntax = "proto3";
package greeting;
message GreetRequest {
string message = 1;
}
message GreetResponse {
string message = 1;
}
service Greeting {
rpc Greet (GreetRequest) returns (GreetResponse);
}
3. Setup Buf to generate SDKs
To generate SDKs we have different solutions:
- Use tonic-build directly from Rust.
- Use the Protobuf CLI protoc and the plugin protoc-gen-tonic.
- Use Buf CLI to manage the SDKs generation.
The first two solutions would fit perfectly but as we want to overengineer our authentication system and think of the not coming future we will use the Buf CLI.
So make sure to install it.
Create the module configuration
Buf CLI works with workspaces and modules to easily split our protobuf definitions (by APIs, microservices, etc).
Let’s make our proto
folder our lonely module by creating a buf.yaml
file with the following line:
# proto/buf.yaml
version: v1
Create the workspace configuration
Now we need to configure our Buf workspace by creating a buf.work.yaml
at the root of our project:
# buf.work.yaml
version: v1
directories:
- proto # <- We define our module in the workspace
Create the generator configuration
We will use four generators:
- protoc-gen-prost The core code generation plugin
- protoc-gen-serde Canonical JSON serialization of protobuf types
- protoc-gen-tonic gRPC service generation for the Tonic framework
- protoc-gen-prost-crate Generates an include file and cargo manifest for turn-key crates
Let’s install them all using the following command:
$ cargo install protoc-gen-prost protoc-gen-prost-serde protoc-gen-tonic protoc-gen-prost-crate
Then, create the buf.gen.yaml
file to configure the SDKs generation:
# buf.gen.yaml
version: v1
plugins:
- plugin: prost # Generates the core code
out: gen/src
opt:
- bytes=.
- compile_well_known_types
- extern_path=.google.protobuf=::pbjson_types
- file_descriptor_set
- plugin: prost-serde # Generates code compatible with JSON serde
out: gen/src
- plugin: tonic # Generates the Tonic services
out: gen/src
opt:
- compile_well_known_types
- extern_path=.google.protobuf=::pbjson_types
- plugin: prost-crate # Makes the gen folder a crate
out: gen
opt:
- gen_crate=gen/Cargo.toml
We now need to create the Cargo.toml
that will be used as a template to generate the new one.
For simplicity we will use the generated one as a template so it can be replaced.
# gen/Cargo.toml
[package]
name = "protos"
version = "0.1.0"
edition = "2021"
[features]
default = ["proto_full"]
# @@protoc_deletion_point(features)
# This section is automatically generated by protoc-gen-prost-crate.
# Changes in this area may be lost on regeneration.
# @@protoc_insertion_point(features)
[dependencies]
bytes = "1.1.0"
prost = "0.12"
pbjson = "0.6"
pbjson-types = "0.6"
serde = "1.0"
tonic = { version = "0.10", features = ["gzip"] }
We can now generate our crate using the command buf generate
.
🎉 Our SDK is now ready!
4. Setup the Rust project
Now that we have our SDK we can start creating the core of our server.
First create a Cargo.toml
file and add our generate crate to the dependencies aswell as all the requirements for this project.
[package]
name = "proto-auth-demo"
version = "0.1.0"
edition = "2021"
[dependencies]
diesel = { version = "2.1.3", features = ["postgres"] }
dotenvy = "0.15.7"
prost = "0.12.1"
protobuf = "3.3.0"
serde = "1.0.190"
tokio = { version = "1.33.0", features = ["full"] }
tonic = "0.10.2"
protos = { path = "./gen" }
bcrypt = "0.15.0"
jwt = "0.16.0"
hmac = "0.12.1"
sha2 = "0.10.8"
[workspace]
members = [
"gen"
]
We will need two environment variables:
-
DATABASE_URL
: To authenticate to our PostgreSQL database -
APP_KEY
: To encrypt user passwords
Store them in a .env
file, we will use them later using the dotenvy crate.
# .env
DATABASE_URL=postgres://rustproto:rustproto@localhost/rustproto
APP_KEY="9E3CnfSfsi9BGfX3Dea#tkbs#nDj&6d#6Y&jhNa!"
And we can now create our main.rs
file:
// src/main.rs
use dotenvy::dotenv;
#[tokio::main]
async fn main() -> Result<(), Box<dyn std::error::Error>> {
dotenv().ok();
Ok(())
}
And build our project using cargo build
.
5. Use Diesel to manage our users
Setup Diesel
First install the Diesel CLI using the following command:
$ cargo install diesel_cli
You may need to install
libpq-dev
,libmysqlclient-dev
andlibsqlite3-dev
to install the CLI.
Create the migrations folder:
$ diesel setup
And add the following lines to the top of your main.rs
(we will create those modules later):
// src/main.rs
mod models;
mod schema;
Create the migration
Let’s first generate the migration to create and drop the users
table.
$ diesel migration generate create_users
-- migrations/*-create_users/up.sql
CREATE TABLE users (
id SERIAL PRIMARY KEY,
email VARCHAR(255) UNIQUE NOT NULL,
password VARCHAR(255) NOT NULL,
firstname VARCHAR(255) NOT NULL,
lastname VARCHAR(255) NOT NULL
);
-- migrations/*-create_users/down.sql
DROP TABLE users;
And run the following command to run the migrations and generate the schema.rs
file:
$ diesel migration run
Create the User model
Create a new file src/models.rs
and add our User model to it and implements the methods to create a new User and find one by email.
// src/models.rs
use diesel::{
ExpressionMethods, Insertable, PgConnection, QueryDsl, Queryable, RunQueryDsl, Selectable,
SelectableHelper,
};
use crate::schema::users;
#[derive(Queryable, Selectable)]
#[diesel(table_name = users)]
#[diesel(check_for_backend(diesel::pg::Pg))]
pub struct User {
pub id: i32,
pub firstname: String,
pub lastname: String,
pub email: String,
pub password: String,
}
#[derive(Insertable)]
#[diesel(table_name = users)]
pub struct NewUser<'a> {
pub firstname: &'a str,
pub lastname: &'a str,
pub email: &'a str,
pub password: &'a str,
}
impl User {
pub fn create(
conn: &mut PgConnection,
firstname: &str,
lastname: &str,
email: &str,
password: &str,
) -> Result<User, diesel::result::Error> {
let new_user = NewUser {
firstname,
lastname,
email,
password,
};
diesel::insert_into(users::table)
.values(new_user)
.returning(User::as_returning())
.get_result(conn)
}
pub fn find_by_email(conn: &mut PgConnection, email: &str) -> Option<User> {
users::dsl::users
.select(User::as_select())
.filter(users::dsl::email.eq(email))
.first(conn)
.ok()
}
}
Create the database connection
We now have to setup the database connection and we will be done with Diesel.
// src/main.rs
use std::env;
use diesel::{PgConnection, Connection};
use dotenvy::dotenv;
mod models;
mod schema;
pub fn connect_db() -> PgConnection {
let database_url = env::var("DATABASE_URL").expect("DATABASE_URL must be set");
PgConnection::establish(&database_url)
.unwrap_or_else(|_| panic!("Error connecting to {}", database_url))
}
#[tokio::main]
async fn main() -> Result<(), Box<dyn std::error::Error>> {
dotenv().ok();
let mut database = connect_db();
Ok(())
}
You can try it by creating a user using the database connection
User.create(&mut database, "", "", "", "")
6. Implement the Tokio Services
It is now time to create the business logic for our authentication system.
We will start with the biggest part, the authentication.
Create the skeleton
use std::sync::{Arc, Mutex};
use diesel::PgConnection;
use protos::auth::{auth_server::Auth, LoginRequest, Token, RegisterRequest};
use tonic::{Request, Response, Status};
use crate::models::User;
pub struct Service {
database: Arc<Mutex<PgConnection>>,
}
impl Service {
pub fn new(database: PgConnection) -> Self {
Self {
database: Arc::new(Mutex::new(database))
}
}
fn generate_token(user: User) -> Token {
unimplemented!();
}
}
#[tonic::async_trait]
impl Auth for Service {
async fn login(&self, request: Request<LoginRequest>) -> Result<Response<Token>, Status> {
unimplemented!();
}
async fn register(&self, request: Request<RegisterRequest>) -> Result<Response<Token>, Status> {
unimplemented!();
}
}
Start the Tonic Server and add our unimplemented service
In the main.rs
file we are going to create a server, add our service to it and start it.
#[tokio::main]
async fn main() -> Result<(), Box<dyn std::error::Error>> {
dotenv().ok();
let database = connect_db();
let addr = "[::1]:50051".parse()?;
Server::builder()
.add_service(AuthServer::new(auth::Service::new(database)))
.serve(addr)
.await?;
Ok(())
}
You can try your server by using the following command to call the auth.Auth/Login
function (package.Service/Method
).
$ grpcurl -plaintext -import-path ./proto -proto auth.proto '[::1]:50051' auth.Auth/Login
You should see in the console of your server the following error:
thread 'tokio-runtime-worker' panicked at 'not implemented', src/auth.rs:22:9
This error has been thrown by the unimplemented!
macro of our Auth Service, it works!
Generate an access token
We are going to use the jwt crate to create a JWT token. It will contains the following claims:
-
sub
: The Subject of the JWT (our user id) -
iat
: Time at which the JWT was issued -
exp
: Time after which the JWT expires
Implement the register method
The register method is fairly simple, it directly takes the request message to create the entry in our database after encrypting the password.
// src/auth.rs
async fn register(&self, request: Request<RegisterRequest>) -> Result<Response<Token>, Status> {
let database = self.database.lock();
let data = request.into_inner();
let password = bcrypt::hash(&data.password, 10)
.map_err(|_| Status::unknown("Error while creating the user"))?;
let user = NewUser {
firstname: &data.firstname,
lastname: &data.lastname,
email: &data.email,
password: &password,
};
let user = User::create(&mut database.unwrap(), user);
unimplemented!();
}
You can already try it! It will throw an error because of the
unimplemented
but your user should be created in the database.
Implement the generate token method
We are going to split our function in two, the part for generating the claims and the one for encoding the token.
We are going to use the APP_KEY
defined in our .env
file to sign the JWT.
// src/auth.rs
pub struct GenerateTokenError;
pub struct GenerateClaimsError;
fn generate_claims(user: User) -> Result<BTreeMap<&'static str, String>, GenerateClaimsError> {
let mut claims: BTreeMap<&str, String> = BTreeMap::new();
claims.insert("sub", user.id.to_string());
let current_timestamp = SystemTime::now()
.duration_since(UNIX_EPOCH)
.map_err(|_| GenerateClaimsError)?
.as_secs();
claims.insert("iat", current_timestamp.to_string());
claims.insert("exp", String::from("3600"));
Ok(claims)
}
fn generate_token(user: User) -> Result<Token, GenerateTokenError> {
let app_key: String = env::var("APP_KEY").expect("env APP_KEY is not defined");
let key: Hmac<Sha256> =
Hmac::new_from_slice(app_key.as_bytes()).map_err(|_| GenerateTokenError)?;
let claims = generate_claims(user).map_err(|_| GenerateTokenError)?;
let access_token = claims.sign_with_key(&key).map_err(|_| GenerateTokenError)?;
Ok(Token {
access_token: access_token,
})
}
And now, let’s use this function to return an access token when a user is registered:
// src/auth.Rs
impl Auth for Service {
[...]
async fn register(&self, request: Request<RegisterRequest>) -> Result<Response<Token>, Status> {
let database = self.database.lock();
let data = request.into_inner();
let password = bcrypt::hash(&data.password, 10)
.map_err(|_| Status::unknown("Error while creating the user"))?;
let user = NewUser {
firstname: &data.firstname,
lastname: &data.lastname,
email: &data.email,
password: &password,
};
let user = User::create(&mut database.unwrap(), user)
.map_err(|_| Status::already_exists("User already exists in the database"))?;
let token = generate_token(user).map_err(|_| Status::unknown("Cannot generate a token for the User"))?;
Ok(Response::new(token))
}
}
You can create a new user with the following command:
$ grpcurl -plaintext -import-path ./proto -proto auth.proto -d '{"firstname": "John", "lastname": "Doe", "email": "john@doe.com", "password": "rustproto"}' '[::1]:50051' auth.Auth/Register
And if you run it again, you will have the error AlreadyExists
. 🎉
Implement the login method
The login method is now really simple, we try to find a user correspond to the email in the message, verify if the password is correct and use the generate_token
method to return the Response.
// src/auth.rs
impl Auth for Service {
[...]
async fn login(&self, request: Request<LoginRequest>) -> Result<Response<Token>, Status> {
let data = request.into_inner();
let database = self.database.lock();
let user = User::find_by_email(&mut database.unwrap(), &data.email)
.ok_or(Status::unauthenticated("Invalid email or password"))?;
match verify(data.password, &user.password) {
Ok(true) => (),
Ok(false) | Err(_) => return Err(Status::unauthenticated("Invalid email or password")),
};
let reply = generate_token(user)
.map_err(|_| Status::unauthenticated("Invalid email or password"))?;
Ok(Response::new(reply))
}
[...]
}
And we can now generate a token using the email and password of our previously registered user!
$ grpcurl -plaintext -import-path ./proto -proto auth.proto -d '{"email": "john@doe.com", "password": "rustproto"}' '[::1]:50051' auth.Auth/Login
Implement the verify token method
As this post already starts to be really long, we will make the verification simple, we will only check for the signature and return true if it is valid.
// src/auth.rs
pub struct VerifyTokenError;
pub fn verify_token(token: &str) -> Result<bool, VerifyTokenError> {
let app_key: String = env::var("APP_KEY").expect("env APP_KEY is not defined");
let key: Hmac<Sha256> =
Hmac::new_from_slice(app_key.as_bytes()).map_err(|_| VerifyTokenError)?;
Ok(token
.verify_with_key(&key)
.map(|_: HashMap<String, String>| true)
.unwrap_or(false))
}
Implement the Greeting service
In a new src/greeting.rs
file we are going to implement our Greeting service using the trait provided by our generated SDk.
We will verify that we have a x-authorization
token in the metadata and verify its value.
// src/greeting.rs
use protos::greeting::{greeting_server::Greeting, GreetRequest, GreetResponse};
use tonic::{Request, Response, Status};
use crate::auth;
#[derive(Default)]
pub struct Service {}
#[tonic::async_trait]
impl Greeting for Service {
async fn greet(
&self,
request: Request<GreetRequest>,
) -> Result<Response<GreetResponse>, Status> {
let token = request
.metadata()
.get("x-authorization")
.ok_or(Status::unauthenticated("No access token specified"))?
.to_str()
.map_err(|_| Status::unauthenticated("No access token specified"))?;
match auth::verify_token(token) {
Ok(true) => (),
Err(_) | Ok(false) => return Err(Status::unauthenticated("Invalid token")),
}
let data = request.into_inner();
Ok(Response::new(GreetResponse {
message: format!("{} {}", data.message, "Pong!"),
}))
}
}
We can now add our service to the Tonic server in main.rs
.
#[tokio::main]
async fn main() -> Result<(), Box<dyn std::error::Error>> {
dotenv().ok();
let database = connect_db();
let addr = "[::1]:50051".parse()?;
Server::builder()
.add_service(AuthServer::new(auth::Service::new(database)))
.add_service(GreetingServer::new(greeting::Service::default()))
.serve(addr)
.await?;
Ok(())
}
It’s now time to try our authentication system! You can use the following command and replace the access token with one generated with the Login or Register method:
$ grpcurl -plaintext -import-path ./proto -proto greeting.proto -H 'x-authorization: ' -d '{"message": "Ping!" }' '[::1]:50051' greeting.Greeting/Greet
Try to put a wrong access token, you will get a unauthenticated status!
You made it 🚀
Rust and Protobuf are new to me, but it is exactly the kind of project that helps me having a great learning experience on things that have a steep learning curve and I hope that it also helped you having a better understanding of Rust, Protobuf and gRPC.
You can find the repository here https://github.com/kerwanp/rust-proto-demo
In the next blog post we will learn how to consume this API in NextJS, so make sure to stay tuned by following me on dev.to/martinp and on Twitter @PaucotMartin.
And if you are stuck, have any question or recommendations, I am here in the comments section!
