Recently, I’ve been designing a data lake to store different types of data from various sources, catering to diverse demands across different areas and levels. To determine the best file type for storing this data, I compiled points of interest, considering the needs and demands of different areas. These points include:

Tool Compatibility

Tool compatibility refers to which tools can write and read a specific file type. No/low code tools are crucial, especially when tools like Excel/LibreOffice play a significant role in operational layers where collaborators may have less technical knowledge to use other tools.

Storage

How much extra or less space will a particular file type cost in the data lake? While non-volatile memory is relatively cheap nowadays, both on-premise and in the cloud, with a large volume of data, any savings and storage optimization can make a difference in the final balance.

Reading

How long do the tools that will consume the data take to open and read the file? In applications where reading seconds matter, sacrificing compatibility and storage for gains in processing time becomes crucial in the data pipeline architecture planning.

Writing

How long will the tools used by our data team take to generate the file in the data lake? If immediate file availability is a priority, this is an attribute we would like to minimize as much as possible.

Query

Some services will directly consume data from the file and perform grouping and filtering functions. Therefore, it’s essential to consider how much time these operations will take to make the correct choice in our data solution.

Benchmark

Files

1 – IBM Transactions for Anti Money Laundering (AML)

Rows: 31 million
Columns: 11
Types: Timestamp, String, Integer, Digital, Boolean

2 – Malware Detection in Network Traffic Data

Rows: 6 million
Columns: 23
Types: String, Integer

Number of Tests

15 tests were conducted for each operation on each file, and the results in the graphs represent the average of each test iteration’s results. The only variable unaffected by the number of tests is the file size, which remains the same regardless of how many times it is written.

Why 2 datasets?

I chose two completely different datasets. The first is significantly larger than the second and contains many null values represented by “-” and many columns with duplicate values where the distinction is low. In contrast, the first dataset has few columns with little data variability and contains more complex types such as timestamps. These characteristics highlight the distinctions, strengths, and weaknesses of each format.

Script

The script used for benchmarking is open on GitHub for anyone who wants to check or conduct their benchmarks with their files, which I strongly recommend.

file-format-benchmark: benchmark script of key operations between different file formats

Tools

I will use Python with Spark for the benchmark. Spark allows native queries on different file types, unlike Pandas, which requires an extra library to achieve this. Additionally, Spark is more performant in handling larger datasets, and the datasets used in this benchmark are relatively large, where Pandas struggled.

Env:
Python version: 3.11.7
Spark version: 3.5.0
Hadoop version: 3.4.1

Benchmark Results

Tool Compatibility

Although I wanted to measure tool compatibility, I couldn’t find a way to do it, so I’ll share my opinion. For pipelines with downstream stakeholders who have more technical knowledge (data scientists, machine learning engineers, etc.), the file format matters little. With a library/framework in any programming language, you can manipulate information from a file in any format. However, for non-technical stakeholders like business analysts, C-level executives, or other collaborators who work directly with product/service production, the scenario changes. These individuals often use tools like Excel, LibreOffice, PowerBI, or Tableau (which, despite having more native readers, do not support Avro or ORC). In cases where files are consumed “manually” by people, you will almost always opt for CSV or JSON. These formats, being plain-text, can be opened, read, and understood in any text editor. Additionally, all kinds of tools can read structured data in files in these formats. Parquet still has some compatibility, being the column storage type with the most support and attention from the community. On the other hand, ORC and Avro have very little support and can be challenging to find parsers and serializers in non-Apache tools.

In summary, CSV and JSON have a significant advantage over the others, and you will likely choose them when your stakeholders are directly handling the files and lack technical knowledge.

Storage

Dataset 1:

Dataset 2:

To calculate storage, we loaded the dataset in CSV format, rewrote it in all formats (including CSV itself), and listed the amount of space they occupy.

The graphs show a significant advantage for JSON, which was three times larger than the second-largest file (CSV) in both cases. The difference is so pronounced due to the way JSON is written, following a schema of a list of objects with key-value pairs, where the key is the column, and the value is the column’s value in that tuple. This results in unnecessary schema redundancy, always inferring the column name in all values. In addition to being plain-text without any compression, similar to CSV, JSON shows the two worst performances in terms of storage. Parquet, ORC, and Avro had very similar results, highlighting their efficiency in storage compared to more common types. The key reasons for this advantage are that Parquet and Avro are binary files, offering a storage advantage. Furthermore, Parquet and ORC are columnar format files that significantly reduce data redundancy, avoiding waste and optimizing space. All three formats have highly efficient compression methods.

In summary, CSV and JSON are by no means the best for storage optimization, especially in cases like storing logs or data with no immediate importance but cannot be discarded.

Reading

Dataset 1:

Dataset 2:

In the reading operation, we timed the dataset loading and printed the first 5 rows.

In reading, there is a peculiar case: despite increasing the file size difference several times (3x), the only format with a visible and relevant difference was JSON. This occurs solely due to the way JSON is written, making it costly for the Spark parser to work with that amount of metadata (redundant schema). The growth in reading time is exponential with the file size. As for why CSV performed as well as ORC and Parquet, it is because CSV is extremely simple, lacking metadata like a schema with types or field names. It is quick for the Spark parser to read, separate, and assess the column types of CSV files, unlike ORC and, especially, Parquet, which have a large amount of metadata useful in cases of files with more fields, complex types, and a larger amount of data. The difference between Avro, Parquet, and ORC is minimal and varies depending on the state of the cluster/machine, simultaneous tasks, and the data file layout. In the case of these datasets in the reading operation, it is challenging to evaluate the difference; it becomes more evident when scaling these files to several times larger than the datasets we are working with.

In summary, CSV, Parquet, ORC, and Avro had almost no difference in reading performance, while JSON cannot be considered as an option in cases where fast data reading is required. Few cases prioritize reading alone; it is generally evaluated along with another task like a query. If you are looking for the most performant file type for this operation, you should consider conducting your own tests.

Writing

Dataset 1:

Dataset 2:

In the writing operation, we read a .csv file and rewrote it in the respective format, only counting the writing time.

In writing, there was a surprise: JSON was not the slowest to be written in the first dataset; it was actually ORC. However, in the second dataset, JSON took the longest. This discrepancy is due to the second dataset having more columns, meaning more metadata to be written. While ORC is a binary file with static typing of data, similar to Parquet, the difference is that ORC applies “better” optimization and compression techniques, requiring more processing power and time. This justifies the query time (which we will see next) and the generated file size, which is smaller in almost all cases than Parquet files. CSV had good performance because it is a very simple format, lacking additional metadata such as schema and types or redundant metadata like JSON. On a larger scale, more complex files would have better performance than CSV. Avro also has its benefits and had a very positive result in dataset 1, outperforming Parquet and ORC with a significant advantage. This probably happened due to the data layout favoring Avro’s optimizations, which differ from Parquet and ORC.

In summary, Avro, despite not being a format with much fame or community support, is a good choice in situations where you want the quick availability of your files for stakeholders to consume. It starts making a difference when scaling to several GBs of data, where the difference becomes 20-30 minutes instead of 30-40 seconds.

Query

Dataset 1:

Dataset 2:

In the query operation, the dataset was loaded, and a query with only one WHERE clause filtering a unique value was performed, followed by printing the respective tuple.

In the first file, all formats had good performance, and the graph scales give the impression that Parquet had poor performance. However, the differences are minimal. Since dataset 2 is much smaller, we believe the query results are very susceptible to external factors. Therefore, we will focus on explaining the results in the first dataset. As mentioned earlier, ORC performs well compared even to Avro, which had excellent performance in other operations. Still, Parquet leads this ranking as the fastest query result. Why? Parquet, being the default format for Spark, indicates much about how the framework works with this format. It incorporates various query optimization techniques, many consolidated in DBMSs. One of the most famous is predicate pushdown, which essentially leaves the WHERE clauses at the end of the execution plan to reduce the amount of data read and examined on the disk. This is an optimization not present in ORC. Why do CSV and JSON lag so far behind? In this case, CSV and JSON are not the problem; the truth is that Parquet and ORC are very well optimized. All the benefits mentioned earlier, such as schema metadata, binary files, and columnar formats, give them a significant advantage. And where does Avro fit into this since it has many of these mentioned benefits? In terms of query optimization, Avro lags far behind ORC and Parquet. One of the points we can mention is column projection, which essentially computes only the specific columns used in the query rather than the entire dataset. This is present in ORC and Parquet but not in Avro. Logically, this is not the only thing that makes ORC and Parquet differ so much from Avro in terms of query optimization, but overall, Avro falls far behind in query optimization.

In summary, when working with large files, with both simple and complex queries, you will want to work with Parquet or ORC. Both have many query optimizations that will deliver results much faster compared to other formats. This difference is already evident in files slightly smaller than dataset 1 and becomes even more apparent in larger files.

Conclusion

In a data engineering environment where you need to serve various stakeholders, consume from various sources, and store data in different storage systems, operations such as reading, writing, or queries are widely affected by the file format. Here, we see what issues certain formats may have, evaluating the main points raised in data environment constructions.

Even though Parquet is the “darling” of the community, we were able to highlight some of its strengths, such as query performance, but also show that there are better options for certain scenarios, such as ORC in storage optimization.

The performances of these operations for each format also depend heavily on the tool you are using and how you are using it (environment and available resources). The results from Spark probably will not differ much from other more robust frameworks like Duckdb or Flink, but we recommend that you conduct your tests before making any decisions that will have a significant impact on other areas of the business.

The post Different file formats, a benchmark doing basic operations appeared first on ProdSens.live.

Spark is an analytics engine for large-scale data engineering. Despite its long history, it still has its well-deserved place in the big data landscape. QuestDB, on the other hand, is a time-series database with a very high data ingestion rate. This means that Spark desperately needs data, a lot of it! …and QuestDB has it, a match made in heaven.

Of course, there is pandas for data analytics! The key here is the expression large-scale. Unlike pandas, Spark is a distributed system and can scale really well.

What does this mean exactly?

Let’s take a look at how data is processed in Spark.

For the purposes of this article, we only need to know that a Spark job consists of multiple tasks, and each task works on a single data partition. Tasks are executed parallel in stages, distributed on the cluster. Stages have a dependency on the previous ones; tasks from different stages cannot run in parallel.

The schematic diagram below depicts an example job:

In this tutorial, we will load data from a QuestDB table into a Spark application and explore the inner working of Spark to refine data loading.
Finally, we will modify and save the data back to QuestDB.

Loading data to Spark

First thing first, we need to load time-series data from QuestDB. I will use an existing table, trades, with just over 1.3 million rows.

It contains bitcoin trades, spanning over 3 days: not exactly a big data scenario but good enough to experiment.

The table contains the following columns:

The table is partitioned by day, and the timestamp column serves as the designated timestamp.

QuestDB accepts connections via Postgres wire protocol, so we can use JDBC to integrate. You can choose from various languages to create Spark applications, and here we will go for Python.

Create the script, sparktest.py:

from pyspark.sql import SparkSession

# create Spark session
spark = SparkSession.builder.appName("questdb_test").getOrCreate()

# load 'trades' table into the dataframe
df = spark.read.format("jdbc")
    .option("url", "jdbc:postgresql://localhost:8812/questdb")
    .option("driver", "org.postgresql.Driver")
    .option("user", "admin").option("password", "quest")
    .option("dbtable", "trades")
    .load()

# print the number of rows
print(df.count())

# do some filtering and print the first 3 rows of the data
df = df.filter(df.symbol == 'BTC-USD').filter(df.side == 'buy')
df.show(3, truncate=False)

Believe it or not, this tiny application already reads data from the database when submitted as a Spark job.

spark-submit --jars postgresql-42.5.1.jar sparktest.py

The job prints the following row count:

1322570

And these are the first 3 rows of the filtered table:

+-------+----+--------+---------+--------------------------+
|symbol |side|price   |amount   |timestamp                 |
+-------+----+--------+---------+--------------------------+
|BTC-USD|buy |23128.72|6.4065E-4|2023-02-01 00:00:00.141334|
|BTC-USD|buy |23128.33|3.7407E-4|2023-02-01 00:00:01.169344|
|BTC-USD|buy |23128.33|8.1796E-4|2023-02-01 00:00:01.184992|
+-------+----+--------+---------+--------------------------+
only showing top 3 rows

Although sparktest.py speaks for itself, it is still worth mentioning that this application has a dependency on the JDBC driver located in postgresql-42.5.1.jar. It cannot run without this dependency; hence it has to be submitted to Spark together with the application.

Optimizing data loading with Spark

We have loaded data into Spark. Now we will look at how this was completed and some aspects to consider.

The easiest way to peek under the hood is to check QuestDB’s log, which should tell us how Spark interacted with the database. We will also make use of the Spark UI, which displays useful insights of the execution, including stages and tasks.

Spark connection to QuestDB: Spark is lazy

QuestDB log shows that Spark connected three times to the database. For simplicity I only show the relevant lines in the log:

2023-03-21T21:12:24.031443Z I pg-server connected [ip=127.0.0.1, fd=129]
2023-03-21T21:12:24.060520Z I i.q.c.p.PGConnectionContext parse [fd=129, q=SELECT * FROM trades WHERE 1=0]
2023-03-21T21:12:24.072262Z I pg-server disconnected [ip=127.0.0.1, fd=129, src=queue]

Spark first queried the database when we created the DataFrame, but as it turns out, it was not too interested in the data itself. The query looked like this:
SELECT * FROM trades WHERE 1=0

The only thing Spark wanted to know was the schema of the table in order to create an empty DataFrame. Spark evaluates expressions lazily, and only does the bare minimum required at each step. After all, it is meant to analyze big data,
so resources are incredibly precious for Spark. Especially memory: data is not cached by default.

The second connection happened when Spark counted the rows of the DataFrame. It did not query the data this time, either. Interestingly, instead of pushing the aggregation down to the database by running SELECT count(*) FROM trades, it
just queried a 1 for each record: SELECT 1 FROM trades.
Spark adds the 1s together to get the actual count.

2023-03-21T21:12:25.692098Z I pg-server connected [ip=127.0.0.1, fd=129]
2023-03-21T21:12:25.693863Z I i.q.c.p.PGConnectionContext parse [fd=129, q=SELECT 1 FROM trades     ]
2023-03-21T21:12:25.695284Z I i.q.c.TableReader open partition /Users/imre/Work/dbroot/db/trades~10/2023-02-01.2 [rowCount=487309, partitionNameTxn=2, transientRowCount=377783, partitionIndex=0, partitionCount=3]
2023-03-21T21:12:25.749986Z I i.q.c.TableReader open partition /Users/imre/Work/dbroot/db/trades~10/2023-02-02.1 [rowCount=457478, partitionNameTxn=1, transientRowCount=377783, partitionIndex=1, partitionCount=3]
2023-03-21T21:12:25.800765Z I i.q.c.TableReader open partition /Users/imre/Work/dbroot/db/trades~10/2023-02-03.0 [rowCount=377783, partitionNameTxn=0, transientRowCount=377783, partitionIndex=2, partitionCount=3]
2023-03-21T21:12:25.881785Z I pg-server disconnected [ip=127.0.0.1, fd=129, src=queue]

Working with the data itself eventually forced Spark to get a taste of the table’s content too. Filters are pushed down to the database by default.

2023-03-21T21:12:26.132570Z I pg-server connected [ip=127.0.0.1, fd=28]
2023-03-21T21:12:26.134355Z I i.q.c.p.PGConnectionContext parse [fd=28, q=SELECT "symbol","side","price","amount","timestamp" FROM trades  WHERE ("symbol" IS NOT NULL) AND ("side" IS NOT NULL) AND ("symbol" = 'BTC-USD') AND ("side" = 'buy')   ]
2023-03-21T21:12:26.739124Z I pg-server disconnected [ip=127.0.0.1, fd=28, src=queue]

We can see that Spark’s interaction with the database is rather sophisticated, and optimized to achieve good performance without wasting resources. The Spark DataFrame is the key component which takes care of the optimization, and it deserves some further analysis.

What is a Spark DataFrame?

The name DataFrame sounds like a container to hold data, but we have seen it earlier that this is not really true. So what is a Spark DataFrame then?

One way to look at Spark SQL, with the risk of oversimplifying it, is that it is a query engine. df.filter(predicate) is really just another way of saying
WHERE predicate. With this in mind, the DataFrame is pretty much a query, or actually more like a query plan.

Most databases come with functionality to display query plans, and Spark has it too! Let’s check the plan for the above DataFrame we just created:

df.explain(extended=True)

== Parsed Logical Plan ==
Filter (side#1 = buy)
+- Filter (symbol#0 = BTC-USD)
   +- Relation [symbol#0,side#1,price#2,amount#3,timestamp#4] JDBCRelation(trades) [numPartitions=1]

== Analyzed Logical Plan ==
symbol: string, side: string, price: double, amount: double, timestamp: timestamp
Filter (side#1 = buy)
+- Filter (symbol#0 = BTC-USD)
   +- Relation [symbol#0,side#1,price#2,amount#3,timestamp#4] JDBCRelation(trades) [numPartitions=1]

== Optimized Logical Plan ==
Filter ((isnotnull(symbol#0) AND isnotnull(side#1)) AND ((symbol#0 = BTC-USD) AND (side#1 = buy)))
+- Relation [symbol#0,side#1,price#2,amount#3,timestamp#4] JDBCRelation(trades) [numPartitions=1]

== Physical Plan ==
*(1) Scan JDBCRelation(trades) [numPartitions=1] [symbol#0,side#1,price#2,amount#3,timestamp#4] PushedFilters: [*IsNotNull(symbol), *IsNotNull(side), *EqualTo(symbol,BTC-USD), *EqualTo(side,buy)], ReadSchema: struct

If the DataFrame knows how to reproduce the data by remembering the execution plan, it does not need to store the actual data. This is precisely what we have seen earlier. Spark desperately tried not to load our data, but this can have disadvantages too.

Caching data

Not caching the data radically reduces Spark’s memory footprint, but there is a bit of jugglery here. Data does not have to be cached because the plan printed above can be executed again and again and again…

Now imagine how a mere decently-sized Spark cluster could make our lonely QuestDB instance suffer martyrdom.

With a massive table containing many partitions, Spark would generate a large number of tasks to be executed parallel across different nodes of the cluster. These tasks would query the table almost simultaneously, putting a heavy load on the database. So, if you find your colleagues cooking breakfast on your database servers, consider forcing Spark to cache some data to reduce the number of trips to the database.

This can be done by calling df.cache(). In a large application, it might require a bit of thinking about what is worth caching and how to ensure that Spark executors have enough memory to store the data.

In practice, you should consider caching smallish datasets used frequently throughout the application’s life.

Let’s rerun our code with a tiny modification, adding .cache():

from pyspark.sql import SparkSession

# create Spark session
spark = SparkSession.builder.appName("questdb_test").getOrCreate()

# load 'trades' table into the dataframe
df = spark.read.format("jdbc")
    .option("url", "jdbc:postgresql://localhost:8812/questdb")
    .option("driver", "org.postgresql.Driver")
    .option("user", "admin").option("password", "quest")
    .option("dbtable", "trades")
    .load()
    .cache()

# print the number of rows
print(df.count())

# print the first 3 rows of the data
df.show(3, truncate=False)

This time Spark hit the database only twice. First, it came for the schema, the second time for the data:
SELECT "symbol","side","price","amount","timestamp" FROM trades.

2023-03-21T21:13:04.122390Z I pg-server connected [ip=127.0.0.1, fd=129]
2023-03-21T21:13:04.147353Z I i.q.c.p.PGConnectionContext parse [fd=129, q=SELECT * FROM trades WHERE 1=0]
2023-03-21T21:13:04.159470Z I pg-server disconnected [ip=127.0.0.1, fd=129, src=queue]
2023-03-21T21:13:05.873960Z I pg-server connected [ip=127.0.0.1, fd=129]
2023-03-21T21:13:05.875951Z I i.q.c.p.PGConnectionContext parse [fd=129, q=SELECT "symbol","side","price","amount","timestamp" FROM trades     ]
2023-03-21T21:13:05.876615Z I i.q.c.TableReader open partition /Users/imre/Work/dbroot/db/trades~10/2023-02-01.2 [rowCount=487309, partitionNameTxn=2, transientRowCount=377783, partitionIndex=0, partitionCount=3]
2023-03-21T21:13:06.259472Z I i.q.c.TableReader open partition /Users/imre/Work/dbroot/db/trades~10/2023-02-02.1 [rowCount=457478, partitionNameTxn=1, transientRowCount=377783, partitionIndex=1, partitionCount=3]
2023-03-21T21:13:06.653769Z I i.q.c.TableReader open partition /Users/imre/Work/dbroot/db/trades~10/2023-02-03.0 [rowCount=377783, partitionNameTxn=0, transientRowCount=377783, partitionIndex=2, partitionCount=3]
2023-03-21T21:13:08.479209Z I pg-server disconnected [ip=127.0.0.1, fd=129, src=queue]

Clearly, even a few carefully placed .cache() calls can improve the overall performance of an application, sometimes significantly. What else should we take into consideration when thinking about performance?

Earlier, we mentioned that our Spark application consists of tasks, which are working on the different partitions of the data parallel. So, partitioned data mean parallelism, which results in better performance.

Spark data partitioning

Now we turn to the Spark UI.

It tells us that the job was done in a single task:

The truth is that we have already suspected this. The execution plan told us (numPartitions=1) and we did not see any parallelism in the QuestDB logs either. We can display more details about this partition with a bit of additional code:

from pyspark.sql.functions import spark_partition_id, min, max, count

df = df.withColumn("partitionId", spark_partition_id())
df.groupBy(df.partitionId)
    .agg(min(df.timestamp), max(df.timestamp), count(df.partitionId))
    .show(truncate=False)

+-----------+--------------------------+--------------------------+------------------+
|partitionId|min(timestamp)            |max(timestamp)            |count(partitionId)|
+-----------+--------------------------+--------------------------+------------------+
|0          |2023-02-01 00:00:00.078073|2023-02-03 23:59:59.801778|1322570           |
+-----------+--------------------------+--------------------------+------------------+

The UI helps us confirm that the data is loaded as a single partition. QuestDB stores this data in 3 partitions. We should try to fix this.

Although it is not recommended, we can try to use DataFrame.repartition(). This call reshuffles data across the cluster while partitioning the data, so it should be our last resort. After running df.repartition(3, df.timestamp), we see 3 partitions, but not exactly the way we expected. The partitions overlap with one another:

+-----------+--------------------------+--------------------------+------------------+
|partitionId|min(timestamp)            |max(timestamp)            |count(partitionId)|
+-----------+--------------------------+--------------------------+------------------+
|0          |2023-02-01 00:00:00.698152|2023-02-03 23:59:59.801778|438550            |
|1          |2023-02-01 00:00:00.078073|2023-02-03 23:59:57.188894|440362            |
|2          |2023-02-01 00:00:00.828943|2023-02-03 23:59:59.309075|443658            |
+-----------+--------------------------+--------------------------+------------------+

It seems that DataFrame.repartition() used hashes to distribute the rows across the 3 partitions. This would mean that all 3 tasks would require data from all 3 QuestDB partitions.

Let’s try this instead: df.repartitionByRange(3, "timestamp"):

+-----------+--------------------------+--------------------------+------------------+
|partitionId|min(timestamp)            |max(timestamp)            |count(partitionId)|
+-----------+--------------------------+--------------------------+------------------+
|0          |2023-02-01 00:00:00.078073|2023-02-01 21:22:35.656399|429389            |
|1          |2023-02-01 21:22:35.665599|2023-02-02 21:45:02.613339|470372            |
|2          |2023-02-02 21:45:02.641778|2023-02-03 23:59:59.801778|422809            |
+-----------+--------------------------+--------------------------+------------------+

This looks better but still not ideal. That is because DaraFrame.repartitionByRange() samples the dataset and then estimates the borders of the partitions.

What we really want is for the DataFrame partitions to match exactly the partitions we see in QuestDB. This way, the tasks running parallel in Spark do not cross their way in QuestDB, likely to result in better performance.

Data source options are to the rescue! Let’s try the following:

from pyspark.sql import SparkSession
from pyspark.sql.functions import spark_partition_id, min, max, count

# create Spark session
spark = SparkSession.builder.appName("questdb_test").getOrCreate()

# load 'trades' table into the dataframe
df = spark.read.format("jdbc")
    .option("url", "jdbc:postgresql://localhost:8812/questdb")
    .option("driver", "org.postgresql.Driver")
    .option("user", "admin").option("password", "quest")
    .option("dbtable", "trades")
    .option("partitionColumn", "timestamp")
    .option("numPartitions", "3")
    .option("lowerBound", "2023-02-01T00:00:00.000000Z")
    .option("upperBound", "2023-02-04T00:00:00.000000Z")
    .load()

df = df.withColumn("partitionId", spark_partition_id())
df.groupBy(df.partitionId)
    .agg(min(df.timestamp), max(df.timestamp), count(df.partitionId))
    .show(truncate=False)

+-----------+--------------------------+--------------------------+------------------+
|partitionId|min(timestamp)            |max(timestamp)            |count(partitionId)|
+-----------+--------------------------+--------------------------+------------------+
|0          |2023-02-01 00:00:00.078073|2023-02-01 23:59:59.664083|487309            |
|1          |2023-02-02 00:00:00.188002|2023-02-02 23:59:59.838473|457478            |
|2          |2023-02-03 00:00:00.565319|2023-02-03 23:59:59.801778|377783            |
+-----------+--------------------------+--------------------------+------------------+

After specifying partitionColumn, numPartitions, lowerBound, and upperBound, the situation is much better: the row counts in the partitions match what we have seen in the QuestDB logs earlier: rowCount=487309, rowCount=457478 and rowCount=377783. Looks like we did it!

2023-03-21T21:13:05.876615Z I i.q.c.TableReader open partition /Users/imre/Work/dbroot/db/trades~10/2023-02-01.2 [rowCount=487309, partitionNameTxn=2, transientRowCount=377783, partitionIndex=0, partitionCount=3]
2023-03-21T21:13:06.259472Z I i.q.c.TableReader open partition /Users/imre/Work/dbroot/db/trades~10/2023-02-02.1 [rowCount=457478, partitionNameTxn=1, transientRowCount=377783, partitionIndex=1, partitionCount=3]
2023-03-21T21:13:06.653769Z I i.q.c.TableReader open partition /Users/imre/Work/dbroot/db/trades~10/2023-02-03.0 [rowCount=377783, partitionNameTxn=0, transientRowCount=377783, partitionIndex=2, partitionCount=3]

We can check Spark UI again; it also confirms that the job was completed in 3 separate tasks, each of them working on a single partition.

Sometimes it might be tricky to know the minimum and maximum timestamps when creating the DataFrame. In the worst case, you could query the database for those values via an ordinary connection.

We have managed to replicate our QuestDB partitions in Spark, but data does not always come from a single table. What if the data required is the result of a query? Can we load that, and is it possible to partition it?

Options to load data: SQL query vs table

We can use the query option to load data from QuestDB with the help of a SQL query:

# 1-minute aggregated trade data
df = spark.read.format("jdbc")
    .option("url", "jdbc:postgresql://localhost:8812/questdb")
    .option("driver", "org.postgresql.Driver")
    .option("user", "admin").option("password", "quest")
    .option("query", "SELECT symbol, sum(amount) as volume, "
                     "min(price) as minimum, max(price) as maximum, "
                     "round((max(price)+min(price))/2, 2) as mid, "
                     "timestamp as ts "
                     "FROM trades WHERE symbol = 'BTC-USD' "
                     "SAMPLE BY 1m ALIGN to CALENDAR")
    .load()

Depending on the amount of data and the actual query, you might find that pushing the aggregations to QuestDB is faster than completing it in Spark. Spark definitely has an edge when the dataset is really large.

Now let’s try partitioning this DataFrame with the options used before with the option dbtable. Unfortunately, we will get an error message:

Options 'query' and 'partitionColumn' can not be specified together.

However, we can trick Spark by just giving the query an alias name. This means we can go back to using the dbtable option again, which lets us specify partitioning. See the example below:

from pyspark.sql import SparkSession
from pyspark.sql.functions import spark_partition_id, min, max, count

# create Spark session
spark = SparkSession.builder.appName("questdb_test").getOrCreate()

# load 1-minute aggregated trade data into the dataframe
df = spark.read.format("jdbc")
    .option("url", "jdbc:postgresql://localhost:8812/questdb")
    .option("driver", "org.postgresql.Driver")
    .option("user", "admin").option("password", "quest")
    .option("dbtable", "(SELECT symbol, sum(amount) as volume, "
                     "min(price) as minimum, max(price) as maximum, "
                     "round((max(price)+min(price))/2, 2) as mid, "
                     "timestamp as ts "
                     "FROM trades WHERE symbol = 'BTC-USD' "
                     "SAMPLE BY 1m ALIGN to CALENDAR) AS fake_table")
    .option("partitionColumn", "ts")
    .option("numPartitions", "3")
    .option("lowerBound", "2023-02-01T00:00:00.000000Z")
    .option("upperBound", "2023-02-04T00:00:00.000000Z")
    .load()

df = df.withColumn("partitionId", spark_partition_id())
df.groupBy(df.partitionId)
    .agg(min(df.ts), max(df.ts), count(df.partitionId))
    .show(truncate=False)

+-----------+-------------------+-------------------+------------------+
|partitionId|min(ts)            |max(ts)            |count(partitionId)|
+-----------+-------------------+-------------------+------------------+
|0          |2023-02-01 00:00:00|2023-02-01 23:59:00|1440              |
|1          |2023-02-02 00:00:00|2023-02-02 23:59:00|1440              |
|2          |2023-02-03 00:00:00|2023-02-03 23:59:00|1440              |
+-----------+-------------------+-------------------+------------------+

Looking good. Now it seems that we can load any data from QuestDB into Spark by passing a SQL query to the DataFrame. Do we, really?

Our trades table is limited to three data types only. What about all the other types you can find in QuestDB?

We expect that Spark will successfully map a double or a timestamp when queried from the database, but what about a geohash? It is not that obvious what is going to happen.

As always, when unsure, we should test.

Type mappings

I have another table in the database with a different schema. This table has a column for each type currently available in QuestDB.

CREATE TABLE all_types (
  symbol SYMBOL,
  string STRING,
  char CHAR,
  long LONG,
  int INT,
  short SHORT,
  byte BYTE,
  double DOUBLE,
  float FLOAT,
  bool BOOLEAN,
  uuid UUID,
  --long128 LONG128,
  long256 LONG256,
  bin BINARY,
  g5c GEOHASH(5c),
  date DATE,
  timestamp TIMESTAMP
) timestamp (timestamp) PARTITION BY DAY;

INSERT INTO all_types values('sym1', 'str1', 'a', 456, 345, 234, 123, 888.8,
  11.1, true, '9f9b2131-d49f-4d1d-ab81-39815c50d341',
  --to_long128(10, 5),
  rnd_long256(), rnd_bin(10,20,2), rnd_geohash(35),
  to_date('2022-02-01', 'yyyy-MM-dd'),
  to_timestamp('2022-01-15T00:00:03.234', 'yyyy-MM-ddTHH:mm:ss.SSS'));

long128 is not fully supported by QuestDB yet, so it is commented out.

Let’s try to load and print the data; we can also take a look at the schema of the DataFrame:

from pyspark.sql import SparkSession

# create Spark session
spark = SparkSession.builder.appName("questdb_test").getOrCreate()

# create dataframe
df = spark.read.format("jdbc")
    .option("url", "jdbc:postgresql://localhost:8812/questdb")
    .option("driver", "org.postgresql.Driver")
    .option("user", "admin").option("password", "quest")
    .option("dbtable", "all_types")
    .load()

# print the schema
print(df.schema)

# print the content of the dataframe
df.show(truncate=False)

Much to my surprise, Spark managed to create the DataFrame and mapped all types.

Here is the schema:

StructType([
  StructField('symbol', StringType(), True),
  StructField('string', StringType(), True),
  StructField('char', StringType(), True),
  StructField('long', LongType(), True),
  StructField('int', IntegerType(), True),
  StructField('short', ShortType(), True),
  StructField('byte', ShortType(), True),
  StructField('double', DoubleType(), True),
  StructField('float', FloatType(), True),
  StructField('bool', BooleanType(), True),
  StructField('uuid', StringType(), True),
#   StructField('long128', StringType(), True),
  StructField('long256', StringType(), True),
  StructField('bin', BinaryType(), True),
  StructField('g5c', StringType(), True),
  StructField('date', TimestampType(), True),
  StructField('timestamp', TimestampType(), True)
])

It looks pretty good but you might wonder if it is a good idea to map long256 and geohash types to String. QuestDB does not provide arithmetics for these types, so it is not a big deal.

Geohashes are basically 32-base numbers, represented and stored in their string format. The 256-bit long values are also treated as string literals. long256 is used to store cryptocurrency private keys.

Now let’s see the data:

+------+------+----+----+---+-----+----+------+-----+----+------------------------------------+
|symbol|string|char|long|int|short|byte|double|float|bool|uuid                                |
+------+------+----+----+---+-----+----+------+-----+----+------------------------------------+
|sym1  |str1  |a   |456 |345|234  |123 |888.8 |11.1 |true|9f9b2131-d49f-4d1d-ab81-39815c50d341|
+------+------+----+----+---+-----+----+------+-----+----+------------------------------------+

+------------------------------------------------------------------+----------------------------------------------------+
|long256                                                           |bin                                                 |
+------------------------------------------------------------------+----------------------------------------------------+
|0x8ee3c2a42acced0bb0bdb411c82bb01e7e487689228c189d1e865fa0e025973c|[F2 4D 4B F6 18 C2 9A A7 87 C2 D3 19 4A 2C 4B 92 C4]|
+------------------------------------------------------------------+----------------------------------------------------+

+-----+-------------------+-----------------------+
|g5c  |date               |timestamp              |
+-----+-------------------+-----------------------+
|q661k|2022-02-01 00:00:00|2022-01-15 00:00:03.234|
+-----+-------------------+-----------------------+

It also looks good, but we could omit the 00:00:00 from the end of the date field. We can see that it is mapped to Timestamp and not Date.

We could also try to map one of the numeric fields to Decimal. This can be useful if later we want to do computations that require high precision.

We can use the customSchema option to customize the column types. Our modified code:

from pyspark.sql import SparkSession

# create Spark session
spark = SparkSession.builder.appName("questdb_test").getOrCreate()

# create dataframe
df = spark.read.format("jdbc")
    .option("url", "jdbc:postgresql://localhost:8812/questdb")
    .option("driver", "org.postgresql.Driver")
    .option("user", "admin").option("password", "quest")
    .option("dbtable", "all_types")
    .option("customSchema", "date DATE, double DECIMAL(38, 10)")
    .load()

# print the schema
print(df.schema)

# print the content of the dataframe
df.show(truncate=False)

The new schema:

StructType([
  StructField('symbol', StringType(), True),
  StructField('string', StringType(), True),
  StructField('char', StringType(), True),
  StructField('long', LongType(), True),
  StructField('int', IntegerType(), True),
  StructField('short', ShortType(), True),
  StructField('byte', ShortType(), True),
  StructField('double', DecimalType(38,10), True),
  StructField('float', FloatType(), True),
  StructField('bool', BooleanType(), True),
  StructField('uuid', StringType(), True),
#   StructField('long128', StringType(), True),
  StructField('long256', StringType(), True),
  StructField('bin', BinaryType(), True),
  StructField('g5c', StringType(), True),
  StructField('date', DateType(), True),
  StructField('timestamp', TimestampType(), True)
])

And the data is displayed as:

+------+------+----+----+---+-----+----+--------------+-----+----+------------------------------------+
|symbol|string|char|long|int|short|byte|double        |float|bool|uuid                                |
+------+------+----+----+---+-----+----+--------------+-----+----+------------------------------------+
|sym1  |str1  |a   |456 |345|234  |123 |888.8000000000|11.1 |true|9f9b2131-d49f-4d1d-ab81-39815c50d341|
+------+------+----+----+---+-----+----+--------------+-----+----+------------------------------------+

+------------------------------------------------------------------+----------------------------------------------------+
|long256                                                           |bin                                                 |
+------------------------------------------------------------------+----------------------------------------------------+
|0x8ee3c2a42acced0bb0bdb411c82bb01e7e487689228c189d1e865fa0e025973c|[F2 4D 4B F6 18 C2 9A A7 87 C2 D3 19 4A 2C 4B 92 C4]|
+------------------------------------------------------------------+----------------------------------------------------+

+-----+----------+-----------------------+
|g5c  |date      |timestamp              |
+-----+----------+-----------------------+
|q661k|2022-02-01|2022-01-15 00:00:03.234|
+-----+----------+-----------------------+

It seems that Spark can handle almost all database types. The only issue is long128, but this type is a work in progress currently in QuestDB. When completed, it will be mapped as String, just like long256.

Writing data back into the database

There is only one thing left: writing data back into QuestDB.

In this example, first, we will load some data from the database and add two new features:

• 10-minute moving average
• standard deviation, also calculated over the last 10-minute window

Then we will try to save the modified DataFrame back into QuestDB as a new table. We need to take care of some type mappings as Double columns are sent as FLOAT8 to QuestDB by default, so we end up with this code:

from pyspark.sql import SparkSession
from pyspark.sql.window import Window
from pyspark.sql.functions import avg, stddev, when

# create Spark session
spark = SparkSession.builder.appName("questdb_test").getOrCreate()

# load 1-minute aggregated trade data into the dataframe
df = spark.read.format("jdbc")
    .option("url", "jdbc:postgresql://localhost:8812/questdb")
    .option("driver", "org.postgresql.Driver")
    .option("user", "admin").option("password", "quest")
    .option("dbtable", "(SELECT symbol, sum(amount) as volume, "
                       "round((max(price)+min(price))/2, 2) as mid, "
                       "timestamp as ts "
                       "FROM trades WHERE symbol = 'BTC-USD' "
                       "SAMPLE BY 1m ALIGN to CALENDAR) AS fake_table")
    .option("partitionColumn", "ts")
    .option("numPartitions", "3")
    .option("lowerBound", "2023-02-01T00:00:00.000000Z")
    .option("upperBound", "2023-02-04T00:00:00.000000Z")
    .load()

# add new features
window_10 = Window.partitionBy(df.symbol).rowsBetween(-10, Window.currentRow)
df = df.withColumn("ma10", avg(df.mid).over(window_10))
df = df.withColumn("std", stddev(df.mid).over(window_10))
df = df.withColumn("std", when(df.std.isNull(), 0.0).otherwise(df.std))

# save the data as 'trades_enriched'
df.write.format("jdbc")
    .option("url", "jdbc:postgresql://localhost:8812/questdb")
    .option("driver", "org.postgresql.Driver")
    .option("user", "admin").option("password", "quest")
    .option("dbtable", "trades_enriched")
    .option("createTableColumnTypes", "volume DOUBLE, mid DOUBLE, ma10 DOUBLE, std DOUBLE")
    .save()

All works but… we soon realize that our new table, trades_enriched is not partitioned and does not have a designated timestamp, which is not ideal. Obviously Spark has no idea of QuestDB specifics.

It would work better if we created the table upfront and Spark only saved the data into it. We drop the table and re-create it; this time, it is partitioned and has a designated timestamp:

DROP TABLE trades_enriched;
CREATE TABLE trades_enriched (
  volume DOUBLE,
  mid DOUBLE,
  ts TIMESTAMP,
  ma10 DOUBLE,
  std DOUBLE
) timestamp (ts) PARTITION BY DAY;

The table is empty and waiting for the data.

We rerun the code; all works, no complaints. The data is in the table, and it is partitioned.

One aspect of writing data into the database is if we are allowed to create duplicates. What if I try to rerun the code again without dropping the table? Will Spark let me save the data this time?
No, we get an error:

pyspark.sql.utils.AnalysisException: Table or view 'trades_enriched' already exists. SaveMode: ErrorIfExists.

The last part of the error message looks interesting: SaveMode: ErrorIfExists.

What is SaveMode? It turns out we can configure what should happen if the table already exists. Our options are:

• errorifexists: the default behavior is to return an error if the table
  already exists, Spark is playing safe here
• append : data will be appended to the existing rows already present in the
  table
• overwrite: the content of the table will be replaced entirely by the newly
  saved data
• ignore: if the table is not empty, our save operation gets ignored without
  any error

We have already seen how errorifexists behaves, append and ignore seem to be simple enough just to work.

However, overwrite is not straightforward. The content of the table must be cleared before the new data can be saved. Spark will delete and re-create the table by default, which means losing partitioning and the designated timestamp.

In general, we do not want Spark to create tables for us. Luckily, with the truncate option we can tell Spark to use TRUNCATE to clear the table instead of deleting it:

# save the data as 'trades_enriched', overwrite if already exists
df.write.format("jdbc")
    .option("url", "jdbc:postgresql://localhost:8812/questdb")
    .option("driver", "org.postgresql.Driver")
    .option("user", "admin").option("password", "quest")
    .option("dbtable", "trades_enriched")
    .option("truncate", True)
    .option("createTableColumnTypes", "volume DOUBLE, mid DOUBLE, ma10 DOUBLE, std DOUBLE")
    .save(mode="overwrite")

The above works as expected.

Conclusion

Our ride might seem bumpy, but we finally have everything
working. Our new motto should be “There is a config option for everything!”.

To summarize what we have found:

• We can use Spark’s JDBC data source to integrate with QuestDB.
• It is recommended to use the dbtable option, even if we use a SQL query to load data.
• Always try to specify partitioning options (partitionColumn, numPartitions, lowerBound and upperBound) when loading data, partitions ideally should match with the QuestDB partitions.
• Sometimes it makes sense to cache some data in Spark to reduce the number of trips to the database.
• It can be beneficial to push work down into the database, depending on the task and how much data is involved. It makes sense to make use of QuestDB’s time-series-specific features, such as SAMPLE BY, instead of trying to rewrite it in Spark.
• Type mappings can be customized via the customSchema option when loading data.
• When writing data into QuestDB always specify the desired saving mode.
• Generally works better if you create the table upfront and do not let Spark create it, because this way you can add partitioning and designated timestamp.
• If selected the overwrite saving mode, you should enable the truncate option too to make sure Spark does not delete the table; hence partitioning and the designated timestamp will not get lost.
• Type mappings can be customized via the createTableColumnTypes option when saving data.

I mentioned only the config options which are most likely to be tweaked when working with QuestDB; the complete set of options can be found here:
Spark data source options.

What could the future bring?

Overall everything works, but it would be nice to have a much more seamless way of integration, where partitioning would be taken care of automagically. Some type mappings could use better defaults, too, when saving data into QuestDB. The
overwrite saving mode could default to use TRUNCATE.

More seamless integration is not impossible to achieve. If QuestDB provided its own JDBCDialect implementation for Spark, the above nuances could be handled.
We should probably consider adding this.

Finally, there is one more thing we did not mention yet, data locality. That is because, currently QuestDB cannot run as a cluster. However, we are actively working on a solution – check out The Inner Workings of Distributed Databases
for more information.

When the time comes, we should ensure that data locality is also considered. Ideally, each Spark node would work on tasks that require partitions loaded from the local (or closest) QuestDB instance.

However, this is not something we should be concerned about at this moment… for now, just enjoy data crunching!

The post Integrate Apache Spark and QuestDB for Time-Series Analytics appeared first on ProdSens.live.
